产品特色
· 超高亮度 亮度值高达大于600 nits~ 5000nits 在户外刺眼阳光下画
面依然清晰明亮
· 超高解析度 解析度已达到 XGA至HDTV的高画质 解析度技术达到超
过3千万像素的电影极画质
· 完美影像重现技术 超乎想象的色彩一致性 影像品质清晰锐利无毛边、
马赛克等模糊影像 超高色彩深度和饱和度 电影级观赏体验
· 安装维修方便
· 超低耗电量
· 直立式/悬吊式
| 室内 |
| 型号 |
DS0808 |
DS0616 |
DS1508 |
DS2012 |
| 点间距 (水平×垂直) |
2×2mm |
2.1×2.2mm |
1.9×1.7mm |
2.5×2.5mm |
| 显示尺寸 (寛×高 |
2.73×0.77m |
2.02×1.58m |
1.64×0.87m |
2.16×1.20m |
| 显示区块数 |
N/A |
N/A |
3 identical(3 separate images optional) |
3 identical(3 separate images optional) |
| 显示区域 |
2.10m2 |
3.25m2 |
4.29m2 |
7.78m2 |
物理分辨率
(水平×垂直) |
1366×384 |
960×720 |
864×512 each×3 |
864×480 each×3 |
| 像素密度 |
250,000/m2 |
216,450/m2 |
309,598/m2 |
160,000/m2 |
| 亮度 (最小值) |
750cd/m2 |
650cd/m2 |
500cd/m2 |
550cd/m2 |
| 均匀度 |
±3% |
±3% |
±3% |
±3% |
| 对比度 |
5000:1 |
5000:1 |
5000:1 |
5000:1 |
| 色谱 |
R=630nm,G=525nm,
B=470nm |
R=630nm,G=525nm,
B=470nm |
R=630nm,G=525nm,
B=470nm |
R=630nm,G=525nm,
B=470nm |
| 建议使用时间 |
75,000 hours |
75,000 hours |
75,000 hours |
75,000 hours |
| 机体尺寸 (直径×高) |
1.00×2.03m |
0.83×2.23m |
1.70×2.58m |
2.23×2.92m |
| 机体重量 |
350kg |
350kg |
600kg |
840kg |
| 机体操作温度 |
0~30oC |
0~30oC |
0~30oC |
0~30oC |
| 防水抗尘等能力 |
|
|
|
|
| 输入电源 |
100-120VAC,25A,1 phase |
200-240VAC,18A,1phase |
200-240VAC,20A,1phase |
200-240VAC,30A,1phase |
| 平均功耗 |
1.5KW |
1.85KW |
2.7KW |
4.35KW |
| 视频接口 |
DVID(1400×1050@60Hz) |
DVI-D(1024×768@60Hz) |
DVI-D(1024×768@60Hz) |
DVI-D(1024×768@60Hz) |
| 刷新率 |
60Hz |
40Hz |
40Hz |
60Hz |
| 内建喇叭组 |
Yes |
Yes |
Yes |
Yes |
| 内容来源 |
Built-in Computer
or Image Scaler |
Built-in Computer
or Image Scaler |
Computer or Image Scaler |
Computer or Image Scaler |
| 悬吊模式 |
Yes |
|
Yes |
Yes |
| 灯箱 |
Available
(w/2 posters 145×92cm) |
|
|
|
| 立地式 |
|
|
1.00m standard,0.75 optional |
1.00m standard,0.75 optional |
| 户外 |
| 型号 |
DS0706 |
DS0716 |
DS1713 |
DS3522 |
| 点间距 (水平×垂直) |
2×2mm |
2×2mm |
2.24×2.2mm |
4×4mm |
| 显示尺寸 (寛×高） |
2.18×0.61m |
2.18×1.54m |
1.77×1.32m |
3.65×2.16m |
| 显示区块数 |
N/A |
N/A |
3 identical(3 separate
images optional) |
3 identical |
| 显示区域 |
1.33m2 |
3.35m2 |
7.03m2 |
23.64m2 |
| 物理分辨率 (水平×垂直) |
1092×304 |
1092×768 |
792×600 each×3 |
912×540 each×3 |
| 像素密度 |
250,000/m2 |
250,000/m2 |
202,922/m2 |
62,500/m2 |
| 亮度 (最小值) |
5,000cd/m2 |
5,000cd/m2 |
5,000cd/m2 |
7,500cd/m2 |
| 均匀度 |
±3% |
±3% |
±3% |
±3% |
| 对比度 |
5000:1 |
5000:1 |
5000:1 |
5000:1 |
| 色谱 |
R=630nm,G=525nm,
B=470nm |
R=630nm,G=525nm,
B=470nm
|
R=630nm,G=525nm,
B=470nm |
R=630nm,G=525nm,
B=470nm |
| 建议使用时间 |
75,000 hours |
75,000 hours |
75,000 hours |
75,000 hours |
| 机体尺寸 (直径×高) |
0.82×2.03m |
0.82×2.80m |
2.00×2.30m |
4.22×4.35m |
| 机体重量 |
470kg |
580kg |
1,300kg |
3,500kg |
| 机体操作温度 |
-20~45oC |
-20~45oC |
-20~45oC |
-20~45oC |
| 防水抗尘等能力 |
IP65(full enclosed
w/air conditioner) |
IP65(full enclosed
w/air conditioner) |
IP65(full enclosed
w/air conditioner) |
IP65(full enclosed
w/air conditioner) |
| 输入电源 |
200-240VAC,25A,1phase |
200-240VAC,
40A,1phase |
200-240VAC,65A,
3phase,3wires |
380-420VAC,85A,
3phase,4wires |
| 平均功耗 |
2.9KW |
4.0KW |
11.8KW |
33.8KW |
| 视频接口 |
DVI-D
(1280×1024@60Hz) |
DVI-D(1280×1024@60Hz) |
DVI-D(1024×768@60Hz) |
DVI-D(1024×768@60Hz) |
| 刷新率 |
90Hz |
90Hz |
60Hz |
120Hz |
| 内建喇叭组 |
Yes |
Yes |
Yes |
No |
| 内容来源 |
Built-in Computer
or Image Scaler |
Built-in Computer
or Image Scaler |
Computer
or Image Scaler |
Computer
or Image Scaler |
| 悬吊模式 |
|
|
|
|
| 灯箱 |
Available(tall stand,
and 0.71m height) |
N/A |
Available
(w/3 posters 180×130cm) |
N/A |
| 立地式 |
|
|
|
| |
