| 产品型号：X300(114W) | | 产品参数SPECIFICATIONS： | | ● 输入电压: 90Vac to 264Vac | | ● 输入电流: 2.5A Max. | | ● 输入频率: 50Hz/60Hz | | ● 输出电压:19V | | ● 输出电流:5.0A | | ● 纹波及杂讯: 300mV max. | | ● 空载损耗功率: ≦0.5W | | ● 转换效率:>80% | | ● 电压调整率/负载调整率:±5% | | ● 耐压测试:3000Vac 50Hz 1minute ≤10mA | | ● 漏电流: Less Than 0.35mA, 230Vac input | | ● 具有过流,过压,过温,短路等保护功能 | | ● 工作温度: -0℃ to +40℃. | | ● 相对湿度: 10～90%RH | | ● 安规标准:1)UL60950/UL60065/EN60950/EN60065/GB4943-1995/GB8898-2001 | | ● 电磁兼容标准:EN55022 CLASS B/GB9254 CLASS B/FCC PART15 CLASS B | | ● 外形尺寸：(L)140mm*(W)50mm *(H)28mm | | ● 重量：* | | | | | | | | Output Voltage 输出电压 | Regulation 调整率 | Min current 最小电流 | Rated current 额定电流 | Peak current 峰值电流 | | +19V | ±5% | 0.02A | 5.0A | *6.0A |
|
