主要特点 无缝衔接的硬件和软件集成,更加可靠运行 弹性显示配置 内容文档设计简单易用 内容文档发布和排期容易 文档内容丰富和通用 独立设置容易配置
内容资源 Local disk or network server 视频文件格式 MPEG1/2, AVI, VOB, MOV, WMV, VC-1, H.264 Flash 文件格式 SWF 图片文件格式 JPG, TIFF, ICP, PNG, GIF, BMP, WMF 声音格式 WAV, SND, MP3, M4A Web/Data Web URL Text files RSS news feed 屏幕支持 1x2/2x1 screen matrix Portrait or Landscape orientation Presentation can be segmented to different screen layouts Up to 9 display zones in each screen layout 播放效果 Scrolling text and emergency message Image transition effect Multiple languages 内容吞吐量 Up to 2 x HD video zones or 1x Full HD video zones Multiple shockwave flash, pictures, and scrolling text zones 管理功能 Web-based management with password access control Multilingual management interface Presentation management Presentation scheduling System event log Presentation playing log Presentation play/Pause/Stop control function System reboot, Shutdown, Firmware upgrade 文档设计 Presentation layout and playlist editing function Presentation and content file preview function Presentation publish function 操作系统 Windows XP Embedded 主板 AMD PhenomII X4 905e quad core processor 内存 1GB DDR2 SDRAM 存储设置 160GB SATA HDD I/O接口 2 x HDMI 2 x Audio line-out 4 x USB 1 x RJ45 with LEDs for 10/100/1000Mbps Ethernet 2 x DB9 for RS-232 4 x COM in terminal port (TX & RX only) 8 x GPIO terminal (4 in, 4 out) 2 x Antenna hole for WiFi and TV tuner 扩展 1 x Mini-PCIe for optional WLAN module 1 x Mini-PCIe for optional TV tuner module 电源供应 1 x External 96W AC/DC adapter;Input: 100~240VAC; Output: +12VDC 体积 272mm (W) x 195mm (D) x 44mm (H) (10.7" x 7.7" x 1.7") w/o mounting bracket 环境 Operating Temperature: Ambient with air flow from 0 to 40°C Storage Temperature: -20 to 85°C Humidity: 10 to 90% (Non-condensing) 认证 CE approval FCC Class A
|
